CAS4FX0NL Hydraulic No Hold Open Bottom Hinge for Framed Door

The Casma FRENUM Hydraulic Hold Open Bottom Patch Hinge for Framed Door is made to be mounted into aluminum stile storefront door or all glass door with full bottom rail. Unique design allows the closing device to be concealed in the rail itself. The Hinge is designed for interior doors up to 220 lbs with maximum width of 39-3/8”.
CAS32400 Pivot is not included, to be ordered separately if needed.

•   No Hold Open

•   Adjustable bottom pivot and closing speed to suit all installation requirements

•   Complies with ASA and ANSI Specifications

•   500,000 cycles

•   Factory preset strengths EN 1154 – 2

•   Max. door weight 220 lbs.

•   Max. door width 39-3/8”

• Factory preset strengths EN 1154 – 2
