SKU: SUB135-ADJ-BN

Sublime Series 135° Hinge - Adjustable

To see the price please, Sign In

Technical Drawing

Same Day Shipping, Orders placed Before 3pm EST

Quality Guarantee

In stock, ready to ship

Shipping Ask about this product

Barcode:

Description

Glaze Hardware Standard duty Adjustable 135° glass-to-glass hinge offers a frameless look while allowing adjustabilty for panels which are not perfectly inline. They are factory configured at 135 degrees for a standard closing position.

Adjustable 135° Glass to Glass Standard Model

Self-Centering Within 15° of Closing Position

Compatible with Monolithic Tempered Glass

Designed For 3/8" Tempered Glass

Available in Different Finishes

BACKPLATE:

135º ANGLE
GLASS THICKNESS:

5/16" - 1/2"
MATERIAL:

BRASS
SELF-CENTERING:

YES
5 DEGREE PRE-SET:

NO
MAX DOOR WEIGHT:

80 LBS (2 HINGES)
MAX DOOR WIDTH:

28 INCH (2 HINGES)
MODEL:

STANDARD DUTY - SUBLIME
MOUNT:

GLASS TO GLASS
ADJUSTABLE:

YES
